PASS/NOZZLE-FEM 3.5. Program Manual

3.2.4. Tab: Structure

The panel "Structure" allows you to set and change the structure attachment parameters, junction type, its placement (fig. 3.6). If you select "No attachment" in the "Project properties" dialog, the Structure tab with this attachment parameters dialog will not be displayed.

For a more detailed description of the structure, see: Structure setting.

Fig. 3.6. Panel for setting nozzle properties.
